Page 1
Specification Sheet
Part Number:
166-90363
Metallic IP68 Compression Fitting, Straight Brass Swivel, 3/4"NPT, 0.75" (25mm) Dia,NPB Metal,10/pkg
Article Number
166-90363
Type
LPC075-S-075
Color
Metal (ML)
Features & Benefits
•
External nickel-plated brass NPT thread provides a durable connection.
•
Swivel feature allows fitting to rotate until tightened. •
Metal ferrule insert has
shallow & longer scroll for stronger fit with LPC smooth bore PVC tubings.
•
IP68 fitting has additional conduit seal for increased protection against wind,
dirt and water.
Quantity Per
pack
Product Description
Multi-part metallic straight compression style fitting for use with LPC non
metallic PVC tubing. Suitable for NPT threaded entries or knocknuts as fitting
rotates until tightened. A longer and shallower scroll allows quick assembly
and more durable fit with smooth bore tubing. Provides IP68 and up to IP69
ingress protection.
Page 2
Short Description
Metallic IP68 Compression Fitting, Straight Brass Swivel, 3/4"NPT, 0.75"
(25mm) Dia,NPB Metal,10/pkg
Global Part Name
LPC075-S-075-NPB-ML
Length L (Imperial)
1.59
Length L (Metric)
40.5
Variant
Straight
Height H (Imperial)
1.38
Height H (Metric)
35.0
Nominal Diameter (Imperial)
3/4
Nominal Diameter (Metric)
25
Material
Nickel Plated Brass (NPB)
Material Shortcut
NPB
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Page 3
Package Quantity(Imperial)
1
Package Quantity (Metric)
10
Customs Number
7412200000
