Specification Sheet
Part Number:
166-90306
HelaGuard Non-Metallic IP66 Fitting, Straight, 1-1/2" NPT Thread, 1.25" Dia, PA66, Black, 2/pkg
Article Number
166-90306
Type
HG125-S-1500
Color
Black (BK)
Features & Benefits
•
External NPT thread provides a secure connection. •
Snap-on construction
reduces installation time and costs by eliminating the need to thread fittings
onto conduits. •
All-around "teeth" attach firmly to conduit and deliver a high
extraction force. •
Durable nylon material has high resistance to salts, oils,
weak acids and solvents. •
IP66 fitting has one-piece construction.
Quantity Per
bag
Product Description
Straight fitting features a snap-on design that provides a quick, secure
connection. Constructed of a very durable nylon material with a high resistance
to salts, oils, weak acids and solvents. Designed for easy removal with a small
screwdriver. IP66 ingress protection rated fittings.
Short Description
HelaGuard Non-Metallic IP66 Fitting, Straight, 1-1/2" NPT Thread, 1.25" Dia,
PA66, Black, 2/pkg
Global Part Name
HG125-S-1500-PA66-BK
Length L (Imperial)
2.32
Length L (Metric)
59
Variant
Straight
Outside Diameter OD(Imperial)
2.48
Outside Diameter OD(metric)
63
Nominal Diameter (Imperial)
1.25
Nominal Diameter (Metric)
42
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
Reach Complaint(Article 33)
Yes
