Specification Sheet
Part Number:
166-90285
HelaGuard Non-Metallic Conduit, Std. Weight, 0.31" Dia, Nylon PA6, Gray, 100ft/reel
Article Number
166-90285
Type
HG-SW0318
Color
Gray (GY)
Features & Benefits
•
Material is easy to use and cut; reduces installation time and labor costs.
•
Flexible, abrasion resistant and durable for a variety of applications. •
Good
impact strength; recovers quickly if crushed. •
UV resistant; suitable for use in
outdoor applications. •
Offered in fine or coarse corrugated pitch.
Quantity Per
reel
Product Description
A standard-weight corrugated conduit made of PA6 nylon that offers flexible
abrasion protection for wire and cable bundles. Easy to cut and use, the
material is highly resistant to solvents and oils. Combine with HelaGuard
non-metallic fittings for IP66 rating or greater protection against water, wind
and dirt.
Short Description
HelaGuard Non-Metallic Conduit, Std. Weight, 0.31" Dia, Nylon PA6, Gray,
100ft/reel
Global Part Name
HG-SW0318-PA6-GY
Length L (Imperial)
100.0
Length L (Metric)
30.5
Outside Diameter OD(Imperial)
0.51
Outside Diameter OD(metric)
13.0
Nominal Diameter (Imperial)
5/16
Nominal Diameter (Metric)
13
Material
Polyamide 6 (PA6)
Material Shortcut
PA6
Flammability
Self-Extinguishing according to EN IEC 61386-1
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +248°F (-40°C to +120°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
