Specification Sheet
Part Number:
166-90232
HelaGuard Non-Metallic IP66 Fitting, Conduit Coupler, 0.75" to 0.75" Dia, PA66, Black, 10/pkg
Article Number
166-90232
Type
HG075-HG075
Color
Black (BK)
Features & Benefits
• One-piece fitting used to join conduits of same diameters. • Snap-on
construction reduces installation time and costs by eliminating the need to
thread fittings onto conduits. • All-around "teeth" attach firmly to conduit and
deliver a high extraction force. • Durable nylon material has high resistance to
salts, oils, weak acids and solvents. • IP66 ingress protection rating against
water, dust and wind.
Quantity Per
bag
Product Description
Used to join two same diameter corrugated conduits together, couplers feature
a snap-on design for a quick, secure connection. Designed for easy removal
with a small screwdriver. Suitable for use on all types of corrugated conduits,
both fine and course pitch material.
Short Description
HelaGuard Non-Metallic IP66 Fitting, Conduit Coupler, 0.75" to 0.75" Dia,
PA66, Black, 10/pkg
Global Part Name
HG075-HG075-PA66-BK
Length L (Imperial)
3.19
Length L (Metric)
81
Variant
Coupler
Outside Diameter OD(Imperial)
1.73
Outside Diameter OD(metric)
44
Nominal Diameter (Imperial)
3/4
Nominal Diameter (Metric)
28
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-58°F to +275°F (-50°C to +135°C)
ROHS Complaint
Yes
