HellermannTyton 166-90178 Specification Sheet

Specification Sheet
Part Number:
166-90178
HelaGuard PACC Conduit Clip, 0.38" Dia, PA66, Black, 10/pkg
166-90178
Type
PACC0380
Color
Black (BK)
Features & Benefits
• Assists with installation by easily cutting through HelaGuard non-mettalic
conduit and tubing.
Product Description
Conduit Clips clamp onto corrugated conduits and tubing to secure. Nylon
material resists corrosion and chemicals. Can also be used on C-shaped DIN
rails.
Short Description
HelaGuard PACC Conduit Clip, 0.38" Dia, PA66, Black, 10/pkg
Global Part Name
PACC0380-PA66-BK
Length L (Imperial)
1.02
Length L (Metric)
26
Variant
Clip
Width W (Imperial)
0.47
Width W (Metric)
12
Height H (Imperial)
1.18
Height H (Metric)
30
Nominal Diameter (Imperial)
3/8
Nominal Diameter (Metric)
16
Mounting Hole Diameter D (Imperial)
0.20
Mounting Hole Diameter D (Metric)
5.0 mm
Mounting Hole Diameter D Max (Metric)
5
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
