HellermannTyton 157-00421 Specification Sheet

Specification Sheet
Part Number:
157-00421
Article Number
Type
T50ROSFT5.6SO25R
Color
Features & Benefits
HIRHSUV solar fasteners provide excellent resistance to UV, chemical and
moisture sensitive environments. •
Can be pre-installed while modules are still
on the pallet. •
Barrel and offset head design reduces potential for abrasion and
wear. •
First Solar vetted design.
Quantity Per
bag
Product Description
The Series 6 Solar Fir Tree Fastener is the easiest and fastest wire
management solution on the market. It features a head design specifically
tailored for First Solar Series 6 Modules. Entire fir tree passes through wire
management hole to prevent unintended disengagement. Unique barrel head
rests on module lip to relieve fir tree of downward forces. Offset keeps bundles
the perfect distance from mounting hole, allowing nondestructive movement
due to wind or tracker motion. The bent tail design allows quick and simple
installations by hand.
Short Description
Series 6 Solar Fir Tree Fastener, 50lb Tensile Strength, PA66HIRHSUV, Black,
1000/bag
Global Part Name
T50ROSFT5.6SO25R-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
222.0
Length L (Imperial)
8.0
Length L (Metric)
203.2
Offset Length(Imperial)
0.98
Offset Length(Metric)
25.0
Fixation Method
Fir Tree
Identification Plate Position
none
Releasable Closure
No
Variant
Outside Serrated
Width W (Imperial)
0.2
Width W (Metric)
5.08
Bundle Diameter Min (Imperial)
0.07
Bundle Diameter Min (Metric)
1.8
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Height H (Imperial)
0.41
Height H (Metric)
10.3
Diameter D (imperial)
0.36
Diameter D (metric)
9.04
Panel Thickness Min(Imperial)
0.19
Panel Thickness Max(Imperial)
0.17
Panel Thickness Min (Metric)
3.0
Panel Thickness Max (Metric)
4.25
Mounting Hole Diameter D (Imperial)
0.22
Mounting Hole Diameter D (Metric)
5.6 mm
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
