Specification Sheet
Part Number:
157-00404
Article Number
157-00404
Type
WSI380
Color
Black (BK)
Features & Benefits
•
Mount provides low insertion and high extraction forces which makes for a
strong and easy installation. •
Tie utilizes a strong hinge between the stud
mount and strap head to provide superior holding ability. •
Clamping rails
increase grip on round bundles. •
Thinner strap provides increased flexibility for
improved ergonomics.
Quantity Per
bag
Product Description
The Wide Strap Stud Mount Cable Tie minimizes pinching on soft bundles and
features a low profile head to provide compact bundling. A thinner strap
provides increased flexibility for improved ergonomics. Available in various stud
mount sizes, the wide strap tie utilizes a strong hinge between the stud mount
and head to provide superior holding ability on a threaded stud.
Short Description
Wide Strap Cable Tie with .38" Stud Mount, 12.7" Long, .5" Wide,
PA66HIRHSUV, Black, 300/Bag
Global Part Name
WSI380-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
120.0
Minimum Tensile Strength (Metric)
534
Length L (Imperial)
12.7
Length L (Metric)
322.6
Fixation Method
Weld Stud Fixing
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.5
Width W (Metric)
12.7
Bundle Diameter Min (Imperial)
0.38
Bundle Diameter Min (Metric)
9.5
Bundle Diameter Max (Imperial)
3.2
Bundle Diameter Max (Metric)
82.5
Stud Diameter (Metric)
M10
Stud Diamater (Imperial)
3/8
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
300
Package Quantity (Metric)
300
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
7.22
