Page 1
Specification Sheet
Part Number:
157-00362
Article Number
157-00362
Type
T50ROSLPM8SMSO25
Color
Black (BK)
Features & Benefits
• Offset design positions bundles away from obstructions, heat or sources of
abrasion. • Low profile head allows mounts to stack, providing more mounting
versatility from a single stud. • Four-pawl, three-tooth design delivers
outstanding stud retention to keep bundles secure.
Quantity Per
carton
Product Description
This mount's offset design positions bundles away from obstructions, heat or
sources of abrasion. It features a low-profile head, allowing multiple tie mounts
to be stacked on a single bolt and providing space savings in tight areas. With
their low insertion force and high extraction performance, HellermannTyton
mounting ties offer the ideal combination of high-grade materials and superior
design to suit the mounting and bundling needs of complex applications.
Available in standard and high-heat material options.
Page 2
Short Description
Offset Low-Profile M8 Stud Mount Tie, 7.5" Tie, 50lb Tensile Strength,
PA66HIRHS, Black, 3000/pkg
Global Part Name
T50ROSLPM8SMSO25-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
223
Length L (Imperial)
8.9
Length L (Metric)
226.14
Offset Length(Imperial)
1.0
Offset Length(Metric)
25.5
Fixation Method
Stud Mount
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.70
Width W (Metric)
17.75
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
Page 3
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Cable Ties
157-00362
Height H (Imperial)
0.25
Height H (Metric)
6.30
Mounting Hole Diameter D (Imperial)
0.31" x 0.05
Mounting Hole Diameter D (Metric)
M8 x 1.25
Stud Diameter (Metric)
8.0 mm
Stud Diamater (Imperial)
0.31
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Page 4
Package Quantity(Imperial)
3000
Package Quantity (Metric)
3000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
0.0027
Weight (Imperial)
0.006
