Specification Sheet
Part Number:
157-00350
Article Number
157-00350
Type
T50ROSM10SO12.5B
Color
Black (BK)
Features & Benefits
• 12.5 mm offset tie with fir tree secures bundles away from obstructions, heat
or sources of abrasion. • Versatile fir tree provides low insertion effort yet
delivers exceptional retention strength in both an 8 mm and M10 threaded
hole. • B series tie secures bundles down below mounting surfaces. • 50lb
rated tie secures bundles up to 50 mm.
Quantity Per
carton
Product Description
Offset Cable Ties route and position wire and cable bundles away from a
mounting hole. The offset bar between the fir tree and cable tie strap provides
a robust and cored-out design to eliminate any potential bending of the wire or
cable assembly once installed. The combination of 12.5 mm and 25 mm offset
distances and various fir tree sizes offer coverage for a majority of industry
offset routing applications. The outside serrations of the tie strap prevent
damage to soft or delicate bundles. One-piece mounting ties offer a complete
solution by both bundling cable and at the same time providing a mounting
solution.
Short Description
Offset Fir Tree Cable Tie, B Series, 12.5mm Offset, 50mm Max Bundle,
PA66HIRHSUV, Black, 3000/ctn
Global Part Name
T50ROSM10SO12.5B-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.52
Length L (Metric)
216.4
Offset Length(Imperial)
0.50
Offset Length(Metric)
12.5
Fixation Method
Fir Tree
Identification Plate Position
none
Releasable Closure
No
Width W (Imperial)
0.19
Width W (Metric)
5.1
