Specification Sheet
Part Number:
157-00344
Article Number
157-00344
Type
T80ROSLPSB12U
Color
Black (BK)
Features & Benefits
• Low-profile head allows mounts to stack, providing more mounting versatility
from a single stud. • Four-pawl, three-tooth design delivers outstanding stud
retention to keep bundles secure. • PA46 material option allows use in
high-heat applications.
Quantity Per
carton
Product Description
Mount features a low-profile head, allowing multiple tie mounts to be stacked
on a single bolt and providing space savings in tight areas. With their low
insertion force and high extraction performance, HellermannTyton mounting
ties offer the ideal combination of high-grade materials and superior design to
suit the mounting and bundling needs of complex applications. Available in
standard and high-heat material options.
Short Description
Low-Profile M12 Stud Mount Tie, 7.5" Tie, 80lb Tensile Strength, PA66HIRHS,
Black, 3000/pkg
Global Part Name
T80ROSLPSB12U-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
80.0
Minimum Tensile Strength (Metric)
355
Length L (Imperial)
8.6
Length L (Metric)
218.0
Fixation Method
Stud Mount
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.93
Width W (Metric)
23.75
Bundle Diameter Min (Imperial)
0.14
Bundle Diameter Min (Metric)
3.5
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
