Page 1
Specification Sheet
Part Number:
157-00329
Blind Hole Mount Cable Tie, Offset, 8"L, .25" Thread/Non-Thread Hole, 50lb, PA66HS, Black, 500/bag
Article Number
157-00329
Type
T50ROSBHMBSO18
Color
Black (BK)
Features & Benefits
•
Offset mount allows wire or cable to be attached beside mounting hole
instead of directly above it. •
Reusable fastener can be extracted from threaded
or nonthreaded holes using a 5/16" hex driver. •
Delivers high extraction force
for reliable performance, yet it’s easy to install. •
Heat stabilized material
provides excellent resistance to high temperatures.
Quantity Per
bag
Page 2
Product Description
Blind Hole Mount Offset Cable Ties secure bundles beside the mounting hole
instead of directly above it. The unique design includes a heat stabilized cable
tie and formula-matched, hex-head fastener that features a low insertion force
and aggressively resists pull off. Performs equally well in threaded or
non-threaded blind holes. Since cable or wire bundle is beside the fastener,
the assembly can be removed using a hex driver from the mounting hole
without cutting the cable tie. The fastener can then be reused.
Short Description
Blind Hole Mount Cable Tie, Offset, 8"L, .25" Thread/Non-Thread Hole, 50lb,
PA66HS, Black, 500/bag
Global Part Name
T50ROSBHMBSO18-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.0
Length L (Metric)
203.2
Offset Length(Imperial)
0.71
Offset Length(Metric)
18.0
Identification Plate Position
none
Releasable Closure
No
Width W (Imperial)
0.185
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.08
Page 3
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Height H (Imperial)
0.736
Height H (Metric)
18.7
Diameter D (imperial)
.25
Diameter D (metric)
6.0
Mounting Hole Diameter D (Imperial)
0.75
Mounting Hole Diameter D (Metric)
19.0 mm
Mounting Hole Diameter D Min (Imperial)
.75
Mounting Hole Diameter D Max (Imperial)
.75
Mounting Hole Diameter D Max (Metric)
19.05
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +257°F (-40°C to +125°C)
Page 4
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
