Specification Sheet
Part Number:
157-00325
Article Number
157-00325
Type
T50ROSM6SMSO25
Color
Black (BK)
Features & Benefits
• Offset design positions bundles away from obstructions, heat or sources of
abrasion. • Four-pawl, three-tooth design delivers outstanding stud retention to
keep bundles secure. • PA46 material option allows use in high-heat
applications.
Quantity Per
carton
Product Description
This mount features an offset design, which positions bundles away from
obstructions, heat or sources of abrasion. With their low insertion force and
high extraction performance, HellermannTyton mounting ties offer the ideal
combination of high-grade materials and superior design to suit the mounting
and bundling needs of complex applications. Available in standard and
high-heat material options.
Short Description
Offset M5/M6 Stud Mount Tie, 7.5" Tie, 50lb Tensile Strength, PA66HIRHS,
BK, 2000/pkg
Global Part Name
T50ROSM6SMSO25-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.8
Length L (Metric)
223.52
Offset Length(Imperial)
1.0
Offset Length(Metric)
25.5
Fixation Method
Stud Mount
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.56
Width W (Metric)
14.2
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
