Specification Sheet
Part Number:
157-00295
Article Number
157-00295
Type
T80ROSSB12U
Color
Brown (BN)
Features & Benefits
•
Covers top of stud for protection from stud end. •
Four-pawl, three-tooth design
delivers outstanding stud retention to keep bundles secure. •
PA46 material
option allows use in high-heat applications.
Quantity Per
carton
Product Description
Stud Mount Ties offer outstanding stud retention. With their low insertion force
and high extraction performance, HellermannTyton mounting ties offer the ideal
combination of high-grade materials and superior design to suit the mounting
and bundling needs of complex applications. Available in standard and
high-heat material options.
Short Description
M12 Stud Mount Tie, 7.5" Tie, 80lb Tensile Strength, PA46, Brown, 3000/pkg
Global Part Name
T80ROSSB12U-PA46-BN
Minimum Tensile Strength (Imperial)
80.0
Minimum Tensile Strength (Metric)
355
Length L (Imperial)
8.6
Length L (Metric)
218.0
Fixation Method
Stud Mount
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.93
Width W (Metric)
23.75
Bundle Diameter Min (Imperial)
0.14
Bundle Diameter Min (Metric)
3.5
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Cable Ties
157-00295
Height H (Imperial)
0.70
