Page 1
Specification Sheet
Part Number:
157-00268
Article Number
157-00268
Type
T50ROSFTSOVAL
Color
Black (BK)
Features & Benefits
•
All-in-one bundling and fastening solution reduces costs and assembly time.
•
Anti-rotational oval fastener forces bundle to travel in intended direction.
•
High-spec materials and superior design deliver excellent performance and
value.
Quantity Per
bag
Product Description
One-piece cable tie and mount offers a simple bundling and mounting solution.
The innovative design of this fir tree establishes a 360-degree interface with
the panel hole, ensuring a more secure fit. The oval shape won’t rotate once
inserted, ensuring proper routing of wires and hoses. The disc feature prevents
rattling in high-vibration applications and protects against debris ingress.
Page 2
Short Description
1-Piece Cable Tie/Fir Tree Mount with Disc, 8.5"L, 6.2 - 13.0 mm, PA66HIRHS,
Black 1000/bag
Global Part Name
T50ROSFTSOVAL-PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.5
Length L (Metric)
215.9
Fixation Method
Fir Tree for oval holes
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.70
Bundle Diameter Min (Imperial)
0.07
Bundle Diameter Min (Metric)
1.8
Bundle Diameter Max (Imperial)
1.97
Page 3
Bundle Diameter Max (Metric)
50.0
Height H (Imperial)
0.32
Height H (Metric)
8.05
Panel Thickness Min(Imperial)
0.023
Panel Thickness Max(Imperial)
0.12
Panel Thickness Min (Metric)
0.6
Panel Thickness Max (Metric)
3.0
Mounting Hole Diameter D (Imperial)
0.24 x 0.48 ";0.25 x 0.50 ";0.25 x 0.51 ";0.27 x 0.47
Mounting Hole Diameter D (Metric)
6.5 x 12.5 mm 6.2 x 12.2 mm 7.0 x 12.0 mm 6.5 x 13.0 mm
Mounting Hole Diameter D Min (Imperial)
0.24
Mounting Hole Diameter D Max (Imperial)
0.51
Mounting Hole Diameter D Max (Metric)
13.0
Disc Diameter(Metric)
17.6 x 23.6
Disc Diameter (Imperial)
0.69 x 0.93
Material
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Material Shortcut
PA66HIRHS
Page 4
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
