Page 1
Specification Sheet
Part Number:
157-00197
Article Number
157-00197
Type
T50ROSFT6S25SO
Color
Black (BK)
Features & Benefits
• One-piece cable tie and fixing offers a simple and easy to use method of
bundling and fixing cables, through the design of the fir tree by ensuring
positive and secure fixing into panels with thicknesses from 0.6-6.65mm. • The
offset on the cable tie creates an alternate solution when an offset fixing option
is required and a tape clip cannot be used due to the design which reduces
the potential of the bundle flexing or shifting. • The 'disc' on the top of the fir
tree covers the hole and minimizes the ingress of water and dirt.
Quantity Per
carton
Product Description
HellermannTyton's Off-Set Fir Tree Cable Tie and fixing offers a simple and
easy to use method of bundling and fixing cables, the design of the fir tree
ensures a positive and secure fixing into panels with thicknesses from .2" -
.26" or threaded blind holes. The 'disc' on the top of the fir tree covers the hole
and minimizes the ingress of water and dirt.
Page 2
Short Description
1-Piece Cable Tie/Offset Fir Tree with Disc, 25 mm, FT6, 8" Tie, 50lb Tensile
Strength, PA66HIRHS, Black, 500/pkg
Global Part Name
T50ROSFT6S25SO-PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
220.0
Length L (Imperial)
9.5
Length L (Metric)
242.2
Offset Length(Imperial)
0.98
Offset Length(Metric)
25.0
Identification Plate Position
none
Releasable Closure
No
Width W (Imperial)
0.20
Width W (Metric)
5.1
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Page 3
Panel Thickness Min(Imperial)
0.02
Panel Thickness Max(Imperial)
0.15
Panel Thickness Min (Metric)
0.60
Panel Thickness Max (Metric)
3.75
Mounting Hole Diameter D (Imperial)
0.24 - 0.27
Mounting Hole Diameter D (Metric)
6.1 - 6.9 mm
Mounting Hole Diameter D Min (Imperial)
0.24
Mounting Hole Diameter D Max (Imperial)
0.27
Mounting Hole Diameter D Max (Metric)
6.9
Disc Diameter (Imperial)
0.75
Material
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Material Shortcut
PA66HIRHS
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Page 4
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
