Page 1
Specification Sheet
Part Number:
157-00168
1-Piece Cable Tie/Fir Tree Mount with Disc, 25mm Offset, 9.1"L, 7.6–8.4 mm Hole, PA46, Brown, 500/pkg
Article Number
157-00168
Type
T50ROSFT8SO25A
Color
Brown (BN)
Features & Benefits
• Off-Set design allows bundles to sit off of mounting points to avoid friction
against surrounding areas. • Fir tree gives 3 to 1 extraction versus insertion
force making them strong and easy to install. • Friction tab inside of fir tree
allows tie to sit in mount without falling out prior to installation.
Quantity Per
box
Product Description
HellermannTyton's Off-Set Fir Tree Cable Tie and fixing offers a simple and
easy to use method of bundling and fixing cables, the design of the fir tree
ensures a positive and secure fixing into panels with thicknesses from .2" -
.26" or threaded blind holes. The 'disc' on the top of the fir tree covers the hole
and minimizes the ingress of water and dirt.
Page 2
Short Description
1-Piece Cable Tie/Fir Tree Mount with Disc, 25mm Offset, 9.1"L, 7.6–8.4 mm
Hole, PA46, Brown, 500/pkg
Global Part Name
T50ROSFT8SO25A-PA46-BN
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
222
Length L (Imperial)
9.1
Length L (Metric)
230.0
Offset Length(Imperial)
0.98
Offset Length(Metric)
25.0
Identification Plate Position
none
Releasable Closure
No
Width W (Imperial)
0.20
Width W (Metric)
5.1
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.6
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Page 3
Height H (Imperial)
0.88
Height H (Metric)
22.30
Panel Thickness Min(Imperial)
0.02
Panel Thickness Max(Imperial)
0.26
Panel Thickness Min (Metric)
0.6
Panel Thickness Max (Metric)
6.65
Mounting Hole Diameter D (Imperial)
0.30 - 0.33
Mounting Hole Diameter D (Metric)
7.6 - 8.4 mm
Mounting Hole Diameter D Min (Imperial)
0.30
Mounting Hole Diameter D Max (Imperial)
0.33
Mounting Hole Diameter D Max (Metric)
8.4
Disc Diameter(Metric)
19.0
Disc Diameter (Imperial)
0.75
Material
Polyamide 4.6 (PA46)
Material Shortcut
PA46
Reach Complaint(Article 33)
Yes
Page 4
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
