Specification Sheet
Part Number:
157-00083
Article Number
157-00083
Type
T50SSBS6OT-E
Color
Black (BK)
Features & Benefits
• Design gives quick and easy assembly by hand without the need for tools. •
Mount can be used in a wide variety of applications where 5mm weld studs or
5mm ISO bolts. • Design provides low insertion force and high extraction force.
Quantity Per
bag
Product Description
The Standoff Stud Mount tie applies easily to weld studs and secures bundles
away from fixing holes. These are used primarily in the automotive industry,
but can be used in a variety of applications.
Short Description
Standoff Stud Mount Tie, 6.0 mm studs, 6.0" Long, PA66HS, Black, 1000/pkg
Global Part Name
T50SSBS6OT-E-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
200
Length L (Imperial)
6.0
Length L (Metric)
160
Fixation Method
Weld Stud Fixing
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.16
Bundle Diameter Min (Metric)
1.0
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Stud Diameter (Metric)
6.0 mm
Stud Diamater (Imperial)
0.24
