Specification Sheet
Part Number:
157-00069
Article Number
157-00069
Type
T50SOS2DOP62X122-E
Color
Gray (GY)
Features & Benefits
•
All-in-one bundling and fastening solution reduces costs and assembly time.
•
Anti-rotational oval fastener forces bundle to travel in intended direction.
•
High-spec materials and superior design deliver excellent performance and
value.
Quantity Per
bag
Product Description
One-piece cable tie and mount offers a simple bundling and mounting solution.
The innovative design of this fir tree establishes a 360-degree interface with
the panel hole, ensuring a more secure fit. The oval shape won’t rotate once
inserted, ensuring proper routing of wires and hoses. The disc feature prevents
rattling in high-vibration applications and protects against debris ingress.
Short Description
1-Piece Cable Tie/Fir Tree Mount with Disc, 6.5"L, 6.2 - 12.2 mm, PA46, Grey,
1000/bag
Global Part Name
T50SOS2DOP62X122-E-PA46-GY
Minimum Tensile Strength (Imperial)
45.0
Minimum Tensile Strength (Metric)
200
Length L (Imperial)
6.5
Length L (Metric)
164.0
Fixation Method
Fir Tree for oval holes
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.04
Bundle Diameter Min (Metric)
1.0
Bundle Diameter Max (Imperial)
1.38
Bundle Diameter Max (Metric)
35.0
Thickness T (Imperial)
0.05
Thickness T (Metric)
1.3
Height H (Imperial)
0.41
Height H (Metric)
10.5
Panel Thickness Min(Imperial)
0.023
Panel Thickness Max(Imperial)
0.24
Panel Thickness Min (Metric)
0.6
Panel Thickness Max (Metric)
6.0
Mounting Hole Diameter D (Imperial)
0.24 - 0.48
Mounting Hole Diameter D (Metric)
6.2 x 12.2 mm
Mounting Hole Diameter D Min (Imperial)
0.24
Mounting Hole Diameter D Max (Imperial)
0.48
Mounting Hole Diameter D Max (Metric)
12.2
Disc Diameter(Metric)
16.0 x 21.0
Disc Diameter (Imperial)
0.63 x 0.83
Material
Polyamide 4.6 (PA46)
Material Shortcut
PA46
Material Cable Tie
Polyamide 4.6 (PA46)
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +275°F (-40°C to +135°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
1.887
