Specification Sheet
Part Number:
157-00054
1-Piece Cable Tie/Fir Tree Mount with Disc, 8.5"L, 7–12 mm Mounting Hole, PA66HS, Black, 500/pkg
Article Number
157-00054
Type
T50ROSFT7X12U
Color
Black (BK)
Features & Benefits
• Outside serrations on the tie strap minimize potential damage to the bundle. •
Low profile tie head design allows the tie to follow the contour of the bundle
and center the bundle directly over the mounting hole. • Tapered and bent tie
strap tail makes it easier to locate and install the strap during the installation
process. • Grips on both sides of the tie strap tail allow for a stronger hold
when tensioning the strap.
Quantity Per
bag
Product Description
Fir Tree Mounts offer a simple and easy-to-use method of bundling and
mounting cables. The design of the fir tree ensures a secure and robust fit into
panels with a 7.0–12.0mm holes and a thickness between 0.6 mm–4.0 mm.
The 'disc' on the top of the fir tree covers the hole and minimizes the ingress
of water and dirt. This can be applied by hand and tensioned with one of
HellermannTyton's manual or pneumatic hand tools.
Short Description
1-Piece Cable Tie/Fir Tree Mount with Disc, 8.5"L, 7–12 mm Mounting Hole,
PA66HS, Black, 500/pkg
Global Part Name
T50ROSFT7X12U-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.5
Length L (Metric)
215.9
Fixation Method
Fir Tree for oval holes
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.2
Width W (Metric)
5.08
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.6
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Thickness T (Imperial)
0.06
Thickness T (Metric)
1.5
Height H (Imperial)
0.41
Height H (Metric)
10.5
Panel Thickness Min(Imperial)
0.023
Panel Thickness Max(Imperial)
0.16
Panel Thickness Min (Metric)
0.6
Panel Thickness Max (Metric)
4.0
Mounting Hole Diameter D (Imperial)
0.28 x 0.47
Mounting Hole Diameter D (Metric)
7.0 x 12.0 mm
Mounting Hole Diameter D Min (Imperial)
0.28
Mounting Hole Diameter D Max (Imperial)
0.47
Mounting Hole Diameter D Max (Metric)
12.0
Disc Diameter(Metric)
15.2 x 20.2
Disc Diameter (Imperial)
0.60 x 0.80
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
