Specification Sheet
Part Number:
156-01887
LOC Locking Clamp, 15-19 mm, to MOC Clip, 12 mm, PA66HIRHSUV, Black, 1000/ctn
Article Number
156-01887
Type
MOC12LOC15-19
Color
Black (BK)
Features & Benefits
• Patented retention design of clip features inverted retaining legs, narrow
opening and circular retainer to prevent inadvertent disengagement. • Clip and
clamp both offer easy bundle installation. • Independent rotation allows for
adjustable routing orientation. • Locking clamp dynamically fits a range of
bundle sizes.
Quantity Per
carton
Product Description
The MOC to LOC is a rotatable dual routing clip and clamp combination that
keeps two routings secured and separated. A swivel coupler allows them to
rotate independently of each other.
Short Description
LOC Locking Clamp, 15-19 mm, to MOC Clip, 12 mm, PA66HIRHSUV, Black,
1000/ctn
Global Part Name
MOC12LOC15-19-PA66HIRHSUV-BK
Length L (Imperial)
1.89
Length L (Metric)
48.00
Variant
Clip to Clamp
Bundle Diameter Min (Imperial)
0.41
Bundle Diameter Min (Metric)
10.5
Bundle Diameter Max (Imperial)
0.54
Bundle Diameter Max (Metric)
13.8
Height H (Imperial)
1.31
Height H (Metric)
33.4
Depth D (imperial)
0.47
Depth D (metric)
12.0
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Weight (Metric)
4.62
Weight (Imperial)
0.16
