Specification Sheet
Part Number:
156-01751
MOC Clip, 16 mm Transverse, Assembled to T50SMVC Swivel Tie, PA66HIRHSUV, Black, 1000/ctn
Article Number
156-01751
Type
T50SMVCMOC16M180
Color
Black (BK)
Features & Benefits
• Patented retention design on clip features inverted retaining legs, narrow
opening and circular retainer to prevent inadvertent disengagement. •
Controlled flex and angled entry promote easy installation. • Independent
rotation allows for adjustable routing orientation. • Cable tie accommodates
wide range of secondary bundle sizes.
Quantity Per
carton
Product Description
The MOC 180 to Swivel Tie is a rotatable routing clip coupled to a cable tie
that keeps two routings secured and separated. Tie provides additional security
against axial slip by clamping around solid tube, pipe or harness. The clip's
orientation allows the second routing to be assembled in the direction of the
first routing. The swivel coupler allows the two routings to rotate independently
of each other.
Short Description
MOC Clip, 16 mm Transverse, Assembled to T50SMVC Swivel Tie,
PA66HIRHSUV, Black, 1000/ctn
Global Part Name
T50SMVCMOC16M180-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
0.90
Length L (Metric)
22.9
Fixation Method
Omega Clips
Identification Plate Position
none
Bundle Diameter Min (Imperial)
0.55
Bundle Diameter Min (Metric)
14.0
Bundle Diameter Max (Imperial)
0.72
Bundle Diameter Max (Metric)
18.3
Height H (Imperial)
1.58
Height H (Metric)
40.2
Depth D (imperial)
0.47
Depth D (metric)
12.0
