Specification Sheet
Part Number:
156-01640
2-Piece Cable Tie/Fir Tree Mount, 8.0" Long, 9–17 mm Mounting Hole, 50lb, PA66HS, Black, 3000/ctn
Article Number
156-01640
Type
T50RFT9X17A2
Color
Black (BK)
Features & Benefits
• 2-Piece assembled fir tree cable tie secures bundles running perpendicular to
9x17 oval mounting hole. • Updated 9x17 mm oval fir tree design maintains
bundle orientation. • Fir tree provides low insertion force with high extration
resistance, for easy assembly and reliable performance. • Disc feature
prevents rattling in high-vibration applicatiosn and protects against debris
ingress.
Quantity Per
carton
Product Description
These two-piece fasteners are pre-assembled and offer a simple and versatile
method of bundling and mounting cables. The fir tree base will easily push into
pre-punched holes in panels or threaded blind holes and offers a secure fit.
The two-piece design enables the head of the tie to be orientated to the
required position to ease assembly, while the disc on top of the fir tree covers
the hole and minimizes the ingress of water and dirt.
Short Description
2-Piece Cable Tie/Fir Tree Mount, 8.0" Long, 9–17 mm Mounting Hole, 50lb,
PA66HS, Black, 3000/ctn
Global Part Name
T50RFT9X17A2-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.0
Length L (Metric)
203.2
Fixation Method
Fir Tree for oval holes
Identification Plate Position
none
Tie Closure
plastic pawl
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.20
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
2.0
