HellermannTyton 156-01564 Specification Sheet

Specification Sheet
Part Number:
156-01564
LOC Locking Clamp, 20–25 mm, Unassembled to T50R Tie, PA66HIRHSUV, Black, 1000/ctn
156-01564
Type
T50RLOC20-25SET
Color
Black (BK)
Features & Benefits
• The 360 degree locking enclosure and cable tie dynamically fit a range of
bundle sizes. • Clamp can be opened for bundle maintenance. • Low-profile
release tab won't interfere with bundle or nearby routing. • The two bundles
are allowed to rotate up to 90 degrees from one another.
Quantity Per
carton
Product Description
The 2-Piece LOC with Saddle to T50R Tie has a two-piece design that keeps
two routings secured together while providing a semi-fixed orientation for each
bundle. The saddle design allows 90-degree rotation of the bundles. Tie
provides additional security against axial slip by clamping around solid tube,
pipe or harness.
Short Description
LOC Locking Clamp, 20–25 mm, Unassembled to T50R Tie, PA66HIRHSUV,
Black, 1000/ctn
Global Part Name
T50RLOC20-25SET-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
1.46
Length L (Metric)
37.2
Fixation Method
Omega Clips
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Bundle Diameter Min (Imperial)
0.79
Bundle Diameter Min (Metric)
20.0
Bundle Diameter Max (Imperial)
0.98
Bundle Diameter Max (Metric)
25.0
Height H (Imperial)
1.53
Height H (Metric)
38.9
Depth D (imperial)
0.47
Depth D (metric)
12.0
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
3.84
Weight (Imperial)
0.14
