Page 1
Specification Sheet
Part Number:
156-01342
1-Piece Cable Ties with Pipe Clip, 19-24.5mm, PA66HIRHS, Black, 500/pkg
Article Number
156-01342
Type
T50SMVCOC19-24.5
Color
Black (BK)
Features & Benefits
•
Bundle can rotate to any orientation, allowing routing in any direction
regardless of mounting point. •
Clip is reusable, making relocation or
adjustments simple. •
All-in-one bundling and mounting solution reduces costs.
Quantity Per
bag
Product Description
HellermannTyton’s 1-Piece Cable Tie with Pipe Clip secures cables to tubular
frame rails. The cable tie bundles wires, cables or tubes, and the C-clip snaps
onto the tubular frame rail. The clip can be removed from the mounting surface
and reinstalled without additional fasteners.
Short Description
1-Piece Cable Ties with Pipe Clip, 19-24.5mm, PA66HIRHS, Black, 500/pkg
Page 2
Global Part Name
T50SMVCOC19-24.5-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
222
Length L (Imperial)
8.3
Length L (Metric)
210.0
Fixation Method
Omega Clips
Identification Plate Position
none
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
50.0
Thickness T (Metric)
1.35
Material
Polyamide 6.6 heat stabilized (PA66HS) Polyamide 6.6, high impact modified,
heat stabilized (PA66HIRHS)
Page 3
Material Shortcut
PA66HIRHS PA66HS
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
