Specification Sheet
Part Number:
156-01341
1-Piece Cable Ties with Pipe Clip, 6.0" Long, Attaches to Diameter .75" - .96", PA66HS, Black, 500/pkg
Article Number
156-01341
Type
T50SVCOC19-24.5
Color
Black (BK)
Features & Benefits
•
Bundle can rotate to any orientation, allowing routing in any direction
regardless of mounting point. •
Clip is reusable, making relocation or
adjustments simple. •
All-in-one bundling and mounting solution reduces costs.
Quantity Per
bag
Product Description
HellermannTyton’s 1-Piece Cable Tie with Pipe Clip secures cables to tubular
frame rails. The cable tie bundles wires, cables or tubes, and the C-clip snaps
onto the tubular frame rail. The clip can be removed from the mounting surface
and reinstalled without additional fasteners.
Short Description
1-Piece Cable Ties with Pipe Clip, 6.0" Long, Attaches to Diameter .75" - .96",
PA66HS, Black, 500/pkg
Global Part Name
T50SVCOC19-24.5-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
222
Length L (Imperial)
6.1
Length L (Metric)
155.0
Fixation Method
Omega Clips
Identification Plate Position
none
Tie Closure
plastic pawl
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Thickness T (Metric)
1.35
