Specification Sheet
Part Number:
156-01340
1-Piece Cable Ties with Pipe Clip, 15-18mm, PA66HIRHS, Black, 500/pkg
Article Number
156-01340
Type
T50SMVCOC15-18
Color
Black (BK)
Features & Benefits
•
Bundle can rotate to any orientation, allowing routing in any direction
regardless of mounting point. •
Clip is reusable, making relocation or
adjustments simple. •
All-in-one bundling and mounting solution reduces costs.
Quantity Per
bag
Product Description
HellermannTyton’s 1-Piece Cable Tie with Pipe Clip secures cables to tubular
frame rails. The cable tie bundles wires, cables or tubes, and the C-clip snaps
onto the tubular frame rail. The clip can be removed from the mounting surface
and reinstalled without additional fasteners.
Short Description
1-Piece Cable Ties with Pipe Clip, 15-18mm, PA66HIRHS, Black, 500/pkg
Global Part Name
T50SMVCOC15-18-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
222
Length L (Imperial)
8.3
Length L (Metric)
210.0
Fixation Method
Omega Clips
Identification Plate Position
none
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.08
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
50.0
Material
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS) Polyamide
6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HIRHS PA66HS
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
