Specification Sheet
Part Number:
156-01292
LOC Locking Clamp, 15–19 mm, Unassembled to T50R Tie, PA66HIRHSUV, Black, 1000/ctn
Article Number
156-01292
Type
T50RLOC15-19-SET
Color
Black (BK)
Features & Benefits
• The 360 degree locking enclosure and cable tie dynamically fit a range of
bundle sizes. • Clamp can be opened for bundle maintenance. • Low-profile
release tab won't interfere with bundle or nearby routing. • The two bundles
are allowed to rotate up to 90 degrees from one another.
Quantity Per
carton
Product Description
The Locking Clip creates a full and secure lock completely around a wire
bundle ranging from 10-14mm. The fixating fir tree on this clip allows for the
clip to be secured into a panel by a 6mm round hole.
Short Description
LOC Locking Clamp, 15–19 mm, Unassembled to T50R Tie, PA66HIRHSUV,
Black, 1000/ctn
Global Part Name
T50RLOC15-19-SET-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
1.24
Length L (Metric)
31.6
Fixation Method
Omega Clips
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Bundle Diameter Min (Imperial)
0.59
Bundle Diameter Min (Metric)
15.0
Bundle Diameter Max (Imperial)
0.75
Bundle Diameter Max (Metric)
19.0
Height H (Imperial)
1.31
Height H (Metric)
33.4
Depth D (imperial)
0.47
Depth D (metric)
12.0
Mounting Hole Diameter D (Imperial)
0.59 - 0.75
Mounting Hole Diameter D (Metric)
15.0 - 19.0 mm
Mounting Hole Diameter D Min (Imperial)
0.61
Mounting Hole Diameter D Max (Imperial)
0.78
Mounting Hole Diameter D Max (Metric)
19.0
Stud Diameter (Metric)
M6
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
3.22
Weight (Imperial)
0.11
