Specification Sheet
Part Number:
156-01289
LOC Locking Clamp, 5–9 mm, Unassembled to T50R Tie, PA66HIRHSUV, Black, 1000/ctn
Article Number
156-01289
Type
T50RLOC5-9-SET
Color
Black (BK)
Features & Benefits
• The 360 degree enclosure ensures the entire bundle is secure when being
routed by this clip. • Locking tab on this clip is small enough that it will not
interfere with any other portion of the wire routing, but is significant enough to
allow for manual disengagement if service is needed. • The cable tie portion of
this two-piece design allows for two wire bundles to be routed with the same
piece.
Quantity Per
carton
Product Description
The Locking Clip creates a full and secure lock completely around a wire
bundle ranging from 10-14mm. The fixating fir tree on this clip allows for the
clip to be secured into a panel by a 6mm round hole.
Short Description
LOC Locking Clamp, 5–9 mm, Unassembled to T50R Tie, PA66HIRHSUV,
Black, 1000/ctn
Global Part Name
T50RLOC5-9-SET-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
0.93
Length L (Metric)
23.7
Fixation Method
Omega Clips
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.47
Width W (Metric)
12.0
Bundle Diameter Min (Imperial)
0.20
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
0.35
Bundle Diameter Max (Metric)
9.0
Height H (Imperial)
0.93
Height H (Metric)
23.6
Depth D (imperial)
0.47
Depth D (metric)
12.0
Mounting Hole Diameter D (Imperial)
0.2 " - 0.35
Mounting Hole Diameter D (Metric)
5.0-9.0 mm
Mounting Hole Diameter D Min (Imperial)
0.20
Mounting Hole Diameter D Max (Imperial)
0.35
Mounting Hole Diameter D Max (Metric)
9
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
2.21
Weight (Imperial)
0.08
