Specification Sheet
Part Number:
156-00953
2-Piece Cable Tie/Fir Tree Mount, 5.8"L, Bundle Dia. 0.16"-1.97" , PA66HIRHSUV/PA66HS, Black, 500/pkg
Article Number
156-00953
Type
T30RFT4
Color
Black (BK)
Features & Benefits
•
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
carton
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Short Description
2-Piece Cable Tie/Fir Tree Mount, 5.8"L, Bundle Dia. 0.16"-1.97" ,
PA66HIRHSUV/PA66HS, Black, 500/pkg
Global Part Name
T30RFT4-PA66HIRHSUV/PA66HS-BK
Minimum Tensile Strength (Imperial)
30.0
Minimum Tensile Strength (Metric)
135
Length L (Imperial)
6.0
Length L (Metric)
148.0
Fixation Method
Fir Tree
Identification Plate Position
none
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.53
Width W (Metric)
13.46
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Height H (Imperial)
0.48
Height H (Metric)
11.8
Panel Thickness Min(Imperial)
0.039
Panel Thickness Max(Imperial)
0.12
Panel Thickness Min (Metric)
1.0
Panel Thickness Max (Metric)
3.0
Mounting Hole Diameter D (Imperial)
0.13 - 0.16
Mounting Hole Diameter D (Metric)
3.3 - 4.0 mm
Mounting Hole Diameter D Min (Imperial)
0.13
Mounting Hole Diameter D Max (Imperial)
0.16
Mounting Hole Diameter D Max (Metric)
4.0
Disc Diameter(Metric)
13
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HIRHSUV PA66HS
Operating Temperature (Metric)
-40°F to +257°F (-40°C to +125°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
