Page 1
Specification Sheet
Part Number:
156-00882
2-Piece Cable Tie/Fir Tree Mount, 8.0"L, .20"–.22" Mounting Hole Diameter, PA66HS, Black, 500/pkg
Article Number
156-00882
Type
T50RFT5.5SD
Color
Black (BK)
Features & Benefits
•
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
carton
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Page 2
Short Description
2-Piece Cable Tie/Fir Tree Mount, 8.0"L, .20"–.22" Mounting Hole Diameter,
PA66HS, Black, 500/pkg
Global Part Name
T50RFT5.5SD-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.0
Length L (Metric)
203.2
Fixation Method
Fir Tree
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.20
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
45.0
Page 3
Thickness T (Imperial)
0.05
Thickness T (Metric)
1.2
Height H (Imperial)
0.05
Panel Thickness Min(Imperial)
0.03
Panel Thickness Max(Imperial)
0.18
Panel Thickness Min (Metric)
0.7
Panel Thickness Max (Metric)
4.5
Mounting Hole Diameter D (Imperial)
0.2 - 0.22
Mounting Hole Diameter D (Metric)
5.0 - 5.7 mm
Mounting Hole Diameter D Min (Imperial)
0.224
Mounting Hole Diameter D Max (Imperial)
0.196
Mounting Hole Diameter D Max (Metric)
5.7
Disc Diameter(Metric)
16.0
Disc Diameter (Imperial)
0.63
Material
Polyamide 6.6 heat stabilized (PA66HS) Polyamide 6.6, high impact modified,
heat stabilized (PA66HIRHS)
Page 4
Material Shortcut
PA66HIRHS PA66HS
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Weight (Metric)
1.9
