Page 1
Specification Sheet
Part Number:
156-00521
Connector Clip with Cable Tie, 7.9" Long, PA66HIRHS, Black, 100/pkg
Article Number
156-00521
Type
T50RYCCB
Color
Black (BK)
Features & Benefits
•
Head design contains clamping rails to provide full circumferential
compression around bundles. •
Bent tail allows for quick insertion into head.
Quantity Per
bag
Product Description
Connector Clips feature various attachment point configurations to
accommodate the many connectors on the market. They are first mated with a
connector on a wire harness or cable assembly, then secured to a surface
using the integrated mount. With so many configurations available, attachment
surfaces can be a hole, edge, stud or even another harness assembly.
Short Description
Connector Clip with Cable Tie, 7.9" Long, PA66HIRHS, Black, 100/pkg
Page 2
Global Part Name
T50RYCCB-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
7.9
Length L (Metric)
200
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Max (Imperial)
1.97
Bundle Diameter Max (Metric)
50.0
Thickness T (Metric)
1.2
Height H (Imperial)
0.30
Height H (Metric)
7.5
Page 3
Material
Polyamide 6.6 heat stabilized (PA66HS) Polyamide 6.6, high impact modified,
heat stabilized (PA66HIRHS)
Material Shortcut
PA66HIRHS PA66HS
Flammability
UL 94 HB UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
