Specification Sheet
Part Number:
156-00457
Heavy Duty Cable Tie/Fir Tree Mount, 8" x .18", .03"–.28", Panel Thickness, PA46, Brown, 500/pkg
Article Number
156-00457
Type
T50RFT7HD
Color
Brown (BN)
Features & Benefits
•
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
bag
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Short Description
Heavy Duty Cable Tie/Fir Tree Mount, 8" x .18", .03"–.28", Panel Thickness,
PA46, Brown, 500/pkg
Global Part Name
T50RFT7HD-PA46-BN
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
8.0
Length L (Metric)
203.2
Fixation Method
Fir Tree
Identification Plate Position
none
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.16
Bundle Diameter Min (Metric)
4.0
Bundle Diameter Max (Imperial)
1.8
Bundle Diameter Max (Metric)
50.0
Height H (Imperial)
.78
Height H (Metric)
19.80
Panel Thickness Min(Imperial)
0.031
Panel Thickness Max(Imperial)
0.276
Panel Thickness Min (Metric)
0.8
Panel Thickness Max (Metric)
7.0
Mounting Hole Diameter D (Imperial)
0.24 - 0.28
Mounting Hole Diameter D (Metric)
6.2 - 7.2 mm
Mounting Hole Diameter D Min (Imperial)
0.244
Mounting Hole Diameter D Max (Imperial)
0.284
Mounting Hole Diameter D Max (Metric)
7.2
Disc Diameter(Metric)
21.6
Disc Diameter (Imperial)
0.9
Material
Polyamide 4.6 (PA46)
Material Shortcut
PA46
Material Cable Tie
Polyamide 4.6 (PA46)
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
