HellermannTyton 156-00092 Specification Sheet

Specification Sheet
Part Number:
156-00092
2-Piece Cable Tie/Fir Tree Mount, 12.0"L, .38"–.39" Mounting Hole, 50lb, PA66HS, Black, 500/pkg
156-00092
Type
T50IFT10
Color
Black (BK)
Features & Benefits
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
bag
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Short Description
2-Piece Cable Tie/Fir Tree Mount, 12.0"L, .38"–.39" Mounting Hole, 50lb,
PA66HS, Black, 500/pkg
Global Part Name
T50IFT10-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
12.0
Length L (Metric)
305.0
Fixation Method
Fir Tree
Identification Plate Position
none
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.16
Bundle Diameter Min (Metric)
4.0
Bundle Diameter Max (Imperial)
3.4
Bundle Diameter Max (Metric)
81.0
Height H (Imperial)
.05
Height H (Metric)
1.20
Panel Thickness Min(Imperial)
0.031
Panel Thickness Max(Imperial)
0.197
Panel Thickness Min (Metric)
0.8
Panel Thickness Max (Metric)
5.0
Mounting Hole Diameter D (Imperial)
0.38 - 0.39
Mounting Hole Diameter D (Metric)
9.7 - 10.0 mm
Mounting Hole Diameter D Min (Imperial)
0.38
Mounting Hole Diameter D Max (Imperial)
0.39
Mounting Hole Diameter D Max (Metric)
10.0
Disc Diameter(Metric)
18.0
Disc Diameter (Imperial)
0.7
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
