HellermannTyton 156-00070 Specification Sheet

Specification Sheet
Part Number:
156-00070
Article Number
Type
Color
Features & Benefits
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
bag
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Short Description
Heavy Duty Cable Tie/Fir Tree Mount, 15" x .5", .04"–.26" Panel Thick,
PA66HIRHSUV, Black, 100/pkg
Global Part Name
WSRFT9A-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
120.0
Minimum Tensile Strength (Metric)
535
Length L (Imperial)
15.0
Length L (Metric)
380.0
Fixation Method
Fir Tree
Identification Plate Position
none
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.5
Width W (Metric)
12.7
Bundle Diameter Max (Imperial)
4.1
Bundle Diameter Max (Metric)
105.0
Height H (Imperial)
.75
Height H (Metric)
19.10
Panel Thickness Min(Imperial)
0.039
Panel Thickness Max(Imperial)
0.256
Panel Thickness Min (Metric)
1.0
Panel Thickness Max (Metric)
6.5
Mounting Hole Diameter D (Imperial)
0.34 - 0.36
Mounting Hole Diameter D (Metric)
8.7 - 9.2 mm
Mounting Hole Diameter D Min (Imperial)
0.34
Mounting Hole Diameter D Max (Imperial)
0.36
Mounting Hole Diameter D Max (Metric)
9.25
Disc Diameter(Metric)
21.6
Disc Diameter (Imperial)
0.85
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
