Specification Sheet
Part Number:
155-30602
Standoff Stud Mount Tie, 5.0 mm studs, 6.0" Long, PA66HS, Black, 500/pkg
Article Number
155-30602
Type
T50SSBS5OT-E
Color
Black (BK)
Features & Benefits
• Design gives quick and easy assembly by hand without the need for tools. •
Mount can be used in a wide variety of applications where 5mm weld studs or
5mm ISO bolts. • Design provides low insertion force and high extraction force.
Quantity Per
bag
Product Description
The Standoff Stud Mount tie applies easily to weld studs and secures bundles
away from fixing holes. These are used primarily in the automotive industry,
but can be used in a variety of applications.
Short Description
Standoff Stud Mount Tie, 5.0 mm studs, 6.0" Long, PA66HS, Black, 500/pkg
Global Part Name
T50SSBS5OT-E-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
200
Length L (Imperial)
6.0
Length L (Metric)
160
Fixation Method
Weld Stud Fixing
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.16
Bundle Diameter Min (Metric)
4.0
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Thickness T (Imperial)
0.05
Thickness T (Metric)
1.35
Stud Length Max (Imperial)
0.65
Stud Length Max (Metric)
16.5
Stud Diameter (Metric)
5.0 mm
Stud Diamater (Imperial)
0.2
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
2.3
