HellermannTyton 151-10953 Specification Sheet

Specification Sheet
Part Number:
151-10953
Q Tag, 5.3" x 2.6", For Q18 thru Q50 ties, PA66, White, 25/bag
151-10953
Type
QT10065R
Color
White (WH)
Features & Benefits
Q-tags are used to identify a cable or a cable bundle and are secured with a
Q-tie. The Q-tag’s flag design allows the user to quickly read or scan the
printed information. The tags can be marked by hand with a marker pen (T82
series) or with a printed adhesive label. HellermannTyton offers a complete
printing solution for Q-tags: printers, labels, ribbons, and market leading label
design software; TagPrint Pro V2. Using Q-ties and Q-tags gives users the
confidence that cables and cable bundles are safely secured and the text is
highly visible.
Quantity Per
bag
Product Description
Q-tags are used to identify a cable or a cable bundle and is secured with a
Q-tie. The Q-tag’s flag design allows the user to quickly read or scan the
printed information. The tags can be marked by hand with a marker pen (T82
series) or with a printed adhesive label. HellermannTyton offers a complete
printing solution for Q-tags: printers, labels, ribbons, and market leading label
design software, TagPrint Pro. Using Q-ties and Q-tags gives users the
confidence that cables and cable bundles are safely secured and the text is
highly visible.
Short Description
Q Tag, 5.3" x 2.6", For Q18 thru Q50 ties, PA66, White, 25/bag
Global Part Name
QT10065R-PA66-WH
Length L (Metric)
135.0
Fixation Method
Others
Variant
Other
Width W (Imperial)
5.31
Width W (Metric)
135.0
Thickness T (Imperial)
0.055
Thickness T (Metric)
1.4
Height H (Imperial)
2.64
Height H (Metric)
67.05
Cable Tie Width Max (Imperial)
0.2
Cable Tie Width Max (Metric)
4.7
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
25
Package Quantity (Metric)
25
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
