Specification Sheet
Part Number:
151-10952
Q Tag, Right Angled, 3.9" x 1.7", For Q18 thru Q30 ties, PA66, White, 50/bag
Article Number
151-10952
Type
QT7040S
Color
White (WH)
Features & Benefits
•
Opening on the tag allows the Q Tie to be easily inserted, providing a secure
identification solution
Quantity Per
bag
Product Description
Q-tags are used to identify a cable or a cable bundle and is secured with a
Q-tie. The Q-tag’s flag design allows the user to quickly read or scan the
printed information. The tags can be marked by hand with a marker pen (T82
series) or with a printed adhesive label. HellermannTyton offers a complete
printing solution for Q-tags: printers, labels, ribbons, and market leading label
design software, TagPrint Pro. Using Q-ties and Q-tags gives users the
confidence that cables and cable bundles are safely secured and the text is
highly visible.
Short Description
Q Tag, Right Angled, 3.9" x 1.7", For Q18 thru Q30 ties, PA66, White, 50/bag
Global Part Name
QT7040S-PA66-WH
Length L (Metric)
88.0
Fixation Method
Others
Variant
Other
Width W (Imperial)
3.46
Width W (Metric)
88.0
Thickness T (Imperial)
0.055
Thickness T (Metric)
1.4
Height H (Imperial)
1.65
Height H (Metric)
42.0
Cable Tie Width Max (Imperial)
0.14
Cable Tie Width Max (Metric)
3.6
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
