Specification Sheet
Part Number:
151-01306
LOC Locking Clamp, 5-9 mm, with 4 x Oval Fir Tree, PA66HIRHSUV, Black, 1700/ctn
Article Number
151-01306
Type
LOC5-9FTOVAL
Color
Black (BK)
Features & Benefits
• The 360 degree locking enclosure dynamically fits a range of bundle sizes. •
Clamp can be opened for bundle maintenance. • Low-profile release tab won't
interfere with bundle or nearby routing. • Non-rotating fir tree demonstrates
easy insertion with high extraction resistance.
Quantity Per
carton
Product Description
The Locking Clip creates a full and secure lock completely around a wire
bundle ranging from 10-14mm. The fixating fir tree on this clip allows for the
clip to be secured into a panel by a 6mm round hole.
Short Description
LOC Locking Clamp, 5-9 mm, with 4 x Oval Fir Tree, PA66HIRHSUV, Black,
1700/ctn
Global Part Name
LOC5-9FTOVAL-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
25
Minimum Tensile Strength (Metric)
110
Length L (Imperial)
1.00
Length L (Metric)
25.5
Fixation Method
Fir Tree
Width W (Imperial)
0.47
Width W (Metric)
12.0
Bundle Diameter Min (Imperial)
0.20
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
0.35
Bundle Diameter Max (Metric)
9.0
Height H (Imperial)
1.35
Height H (Metric)
34.2
Depth D (imperial)
0.47
Depth D (metric)
12.0
Panel Thickness Min(Imperial)
0.02
Panel Thickness Max(Imperial)
0.27
Panel Thickness Min (Metric)
0.60
Panel Thickness Max (Metric)
6.75
Mounting Hole Diameter D (Imperial)
0.24 x 0.48"; 0.26 x 0.49"; 0.26 x 0.51"; 0.28 x 0.47
Mounting Hole Diameter D (Metric)
6.5 x 13.0 mm 7.0 x 12.0 mm 6.2 x 12.2 mm 6.5 x 12.5 mm
Mounting Hole Diameter D Min (Imperial)
0.24
Mounting Hole Diameter D Max (Imperial)
0.51
Mounting Hole Diameter D Max (Metric)
13.0
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1700
Package Quantity (Metric)
1700
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
2.28
Weight (Imperial)
0.08
