Specification Sheet
Part Number:
151-01022
LOC Locking Clamp, 15-19 mm, with 6.5 mm Fir Tree, PA66HIRHSUV, Black, 1000/ctn
Article Number
151-01022
Type
LOC15-19FT6LG
Color
Black (BK)
Features & Benefits
• The 360 degree locking enclosure dynamically fits a range of bundle sizes. •
Clamp can be opened for bundle maintenance. • Low-profile release tab won't
interfere with bundle or nearby routing. • Fir tree demonstrates easy insertion
with high extraction resistance.
Quantity Per
carton
Product Description
The LOC with Round Fir Tree features HellermannTyton's unique retention
clamp attached to a 6.5 mm fir tree. The mount delivers a low insertion force
while exhibiting high extraction resistance for a secure mounting point against
a panel.
Short Description
LOC Locking Clamp, 15-19 mm, with 6.5 mm Fir Tree, PA66HIRHSUV, Black,
1000/ctn
Global Part Name
LOC15-19FT6LG-PA66HIRHSUV-BK
Length L (Imperial)
1.24
Length L (Metric)
31.6
Fixation Method
Fir Tree
Width W (Imperial)
0.47
Width W (Metric)
12.0
Bundle Diameter Min (Imperial)
0.59
Bundle Diameter Min (Metric)
15.0
Bundle Diameter Max (Imperial)
0.75
Bundle Diameter Max (Metric)
19.0
Height H (Imperial)
1.87
Height H (Metric)
47.5
Depth D (imperial)
0.47
Depth D (metric)
12.0
Panel Thickness Min(Imperial)
0.02
