Page 1
Specification Sheet
Part Number:
150-55850
Article Number
150-55850
Type
T30RFT5
Color
Black (BK)
Features & Benefits
•
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
bag
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Short Description
2-Piece Cable Tie/Fir Tree Mount, 6.0"L, .17"–.20" Mounting Hole Diameter,
PA66HS, Black, 500/pkg
Page 2
Global Part Name
T30RFT5-PA66HS/PA66HIRHS-BK
Minimum Tensile Strength (Imperial)
30.0
Minimum Tensile Strength (Metric)
135
Length L (Imperial)
6.0
Length L (Metric)
150.0
Fixation Method
Fir Tree
Identification Plate Position
none
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.14
Width W (Metric)
3.5
Bundle Diameter Min (Imperial)
0.20
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
34.0
Thickness T (Imperial)
0.043
Thickness T (Metric)
1.1
Page 3
Height H (Imperial)
0.04
Height H (Metric)
1.2
Panel Thickness Min(Imperial)
0.03
Panel Thickness Max(Imperial)
0.12
Panel Thickness Min (Metric)
0.7
Panel Thickness Max (Metric)
3.0
Mounting Hole Diameter D (Imperial)
0.17 - 0.2
Mounting Hole Diameter D (Metric)
4.5 - 5.0 mm
Mounting Hole Diameter D Min (Imperial)
0.177
Mounting Hole Diameter D Max (Imperial)
0.197
Mounting Hole Diameter D Max (Metric)
5.0
Disc Diameter(Metric)
16.0
Disc Diameter (Imperial)
0.63
Material
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS) Polyamide
6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HIRHS PA66HS
Page 4
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
1.5
