Specification Sheet
Part Number:
150-55610
1-Piece Cable Tie/Fir Tree Mount with Disc, 4.3"L, .19"–.20" Mounting Hole, PA66, Black, 500/pkg
Article Number
150-55610
Type
T18RDP5
Color
Black (BK)
Features & Benefits
• Fir tree mounts are equipped with a friction tab that will hold the tie in the
mount, allowing them to be preassembled prior to installation. • Fir Tree design
provides low extraction and high extraction force.
Quantity Per
pcs.
Product Description
Fir tree mounts with ties cables provide a secure grip in mounting holes and
protect against dirt and other impurities. This is sold as an assembly with the
cable tie.
Short Description
1-Piece Cable Tie/Fir Tree Mount with Disc, 4.3"L, .19"–.20" Mounting Hole,
PA66, Black, 500/pkg
Global Part Name
T18RDP5-PA66-BK
Minimum Tensile Strength (Imperial)
18.0
Minimum Tensile Strength (Metric)
80
Length L (Imperial)
4.3
Length L (Metric)
110.0
Fixation Method
Fir Tree
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.1
Width W (Metric)
2.5
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
0.8
Bundle Diameter Max (Metric)
20.0
Thickness T (Imperial)
0.043
Thickness T (Metric)
1.1
Panel Thickness Min(Imperial)
0.12
Panel Thickness Max(Imperial)
0.02
Panel Thickness Min (Metric)
3.0
Panel Thickness Max (Metric)
4.0
Mounting Hole Diameter D (Imperial)
0.19 - 0.2
Mounting Hole Diameter D (Metric)
4.9 - 5.1 mm
Mounting Hole Diameter D Min (Imperial)
0.19
Mounting Hole Diameter D Max (Imperial)
0.197
Mounting Hole Diameter D Max (Metric)
5.1
Disc Diameter(Metric)
13.0
Disc Diameter (Imperial)
0.5
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
0.6
