Specification Sheet
Part Number:
148-00095
Wire Clamping Cable Ties, Version A, Diameter Attachment .13", 6.0" Long, Black, PA66HS, 500/pkg
Article Number
148-00095
Type
T50SOSWA3.4E
Color
Black (BK)
Features & Benefits
• Clamp provides low insertion and high extraction force. • Various sizes
available to accommodate all different sizes of bundles. • Clamp can be
installed both before and after installation of bundles.
Quantity Per
bag
Product Description
Wire Clamping Cable Ties secure easily to wire frames for a tight fit and are
available in four different wire frame sizes and two separate orientations to
provide both perpendicular and parallel routing. The wire clamp design is
ideally suited for easing the application process on the production floor by
allowing for an easy snap fit of the harness assembly to the wire frame.
Short Description
Wire Clamping Cable Ties, Version A, Diameter Attachment .13", 6.0" Long,
Black, PA66HS, 500/pkg
Global Part Name
T50SOSWA3.4E-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
6.0
Length L (Metric)
150.0
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.6
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Thickness T (Imperial)
0.05
