Specification Sheet
Part Number:
133-00996
HC Clamp Bundle Separator, Two Hole, PA66GFHIRHS, Natural, 500/pkg
Article Number
133-00996
Type
HC2D
Color
Natural (NA)
Features & Benefits
• Separates and secures bundles avoiding abrasion • Designed to handle both
convoluted tubing and bundles not covered in convoluted tubing • Come in a
variety of sizes and colors to be easily identified
Quantity Per
bag
Product Description
HC Clamps separate multiple bundles and secure them to brackets or frame
rails. Each mount has two pawls for easy pre-installation on a threaded
fastener prior to securing with a mechanical fastener. HC Clamps have ribs
that make them ideal for convoluted tubing, but they can also be used to
separate separate bundles that aren't protected with convoluted tubing.
Short Description
HC Clamp Bundle Separator, Two Hole, PA66GFHIRHS, Natural, 500/pkg
Global Part Name
HC2D-PA66HIRGF13-NA
Length L (Imperial)
2.747
Length L (Metric)
67.77
Width W (Imperial)
1.1
Width W (Metric)
27.94
Bundle Diameter Min (Imperial)
0.65
Bundle Diameter Min (Metric)
16.51
Bundle Diameter Max (Imperial)
0.96
Bundle Diameter Max (Metric)
24.39
Bundle Diameter 1st Loop Max (Imperial)
0.65
Bundle Diameter 1st Loop Max (Metric)
16.51
Bundle Diameter 2nd Loop Max (Imperial)
0.96
Bundle Diameter 2nd Loop Max (Metric)
24.39
Height H (Imperial)
1.38
Height H (Metric)
34.94
Mounting Hole Diameter D (Imperial)
0.32
Mounting Hole Diameter D (Metric)
8.12 mm
