Specification Sheet
Part Number:
132-00034
Button Head Cable Tie with Retainers and Pilot Bushings, 15.0" Long, PA66HIRHSUV, Black, 2000/pkg
Article Number
132-00034
Type
BT130LDP
Color
Black (BK)
Features & Benefits
• Unique two piece tie allows parallel entry and exit through the head for easy
assembly. • High impact, heat stabilized material gives strength needed for
trucking and heavy equipment applications.
Quantity Per
carton
Product Description
The button head tie is a two piece tie providing for parallel entry and exit
through the head. The strap contains serrations on both sides, and has two
opposed pawls recessed within a domed head. This design allows the strap to
be directed clockwise or counter-clockwise prior to insertion into the head,
enabling bi-directional looping.
Short Description
Button Head Cable Tie with Retainers and Pilot Bushings, 15.0" Long,
PA66HIRHSUV, Black, 2000/pkg
Global Part Name
BT130LDP-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
130
Minimum Tensile Strength (Metric)
578
Length L (Imperial)
15.0
Length L (Metric)
381.5
Fixation Method
Connector Clip
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.3
Width W (Metric)
7.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
4.3
Bundle Diameter Max (Metric)
110.0
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Material Head
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
Package Quantity(Imperial)
2000
Package Quantity (Metric)
2000
Customs Number
3926909988
