Specification Sheet
Part Number:
132-00033
Button Head Cable Tie, 9.6" Long, 2.6" Max Bundle Diameter, 105lb, PA66HSUV, Black, 2000/pkg
Article Number
132-00033
Type
BT105R
Color
Black (BK)
Features & Benefits
• Unique two piece tie allows parallel entry and exit through the head for easy
assembly. • PA66HIRHS material make it ideal for trucking and heavy
equipment applications.
Quantity Per
carton
Product Description
The button head tie is a two piece tie providing for parallel entry and exit
through the head. The strap contains serrations on both sides, and has two
opposed pawls recessed within a domed head. This design allows the strap to
be directed clockwise or counter-clockwise prior to insertion into the head,
enabling bi-directional looping.
Short Description
Button Head Cable Tie, 9.6" Long, 2.6" Max Bundle Diameter, 105lb,
PA66HSUV, Black, 2000/pkg
Global Part Name
BT105R-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
105.0
Minimum Tensile Strength (Metric)
467
Length L (Imperial)
9.6
Length L (Metric)
244.4
Fixation Method
Connector Clip
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.2
Width W (Metric)
5.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
2.6
Bundle Diameter Max (Metric)
66.7
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Material Cable Tie
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Material Head
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Package Quantity(Imperial)
2000
Package Quantity (Metric)
2000
Customs Number
3926909988
