Specification Sheet
Part Number:
132-00008
Button Head Cable Tie with Retainers and Pilot Bushings, 10.5" Long, PA66HIRHSUV, Black, 50/pkg
Article Number
132-00008
Type
BT130RDP
Color
Black (BK)
Features & Benefits
• Unique two piece tie allows parallel entry and exit through the head for easy
assembly. • High impact, heat stabilized material gives strength needed for
trucking and heavy equipment applications.
Quantity Per
bag
Product Description
The button head tie is a two piece tie providing for parallel entry and exit
through the head. The strap contains serrations on both sides, and has two
opposed pawls recessed within a domed head. This design allows the strap to
be directed clockwise or counter-clockwise prior to insertion into the head,
enabling bi-directional looping.
Short Description
Button Head Cable Tie with Retainers and Pilot Bushings, 10.5" Long,
PA66HIRHSUV, Black, 50/pkg
Global Part Name
BT130RDP-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
130
Minimum Tensile Strength (Metric)
578
Length L (Imperial)
10.5
Length L (Metric)
267.0
Fixation Method
Connector Clip
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.3
Width W (Metric)
7.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
2.9
