Specification Sheet
Part Number:
126-00082
1-Piece Cable Tie/Arrowhead Mount with Wings, 6"L, 50lb, 0.24 - 0.26" Mtg Hole, PA66HIRHS, Natural,
500/bag
Article Number
126-00082
Type
T50SSFM
Color
Natural (NA)
Features & Benefits
•
Two piece assembly allows the mount to slide along the strap ensuring proper
orientation. •
Arrowhead style mount provides low insertion and high extraction
force. •
Arrowhead disc protects against dirt and other impurities.
Quantity Per
bag
Product Description
Wing design helps stabilize the tie in high vibration applications. One-piece
mounting ties offer a complete solution by both bundling cable and
simultaneously providing a mounting solution. HellermannTyton's one-piece
mounting ties offer the ideal combination of high specification materials and
superior design to suit the mounting and bundling needs of complex
applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount with Wings, 6"L, 50lb, 0.24 - 0.26" Mtg
Hole, PA66HIRHS, Natural, 500/bag
Global Part Name
T50SSFM-PA66HIRHS-NA
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
6.3
Length L (Metric)
160.0
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Height H (Imperial)
0.2
Height H (Metric)
5.6
Panel Thickness Min(Imperial)
0.028
Panel Thickness Max(Imperial)
0.12
Panel Thickness Min (Metric)
0.7
Panel Thickness Max (Metric)
3.0
Mounting Hole Diameter D (Imperial)
0.24 " - 0.26
Mounting Hole Diameter D (Metric)
6.0 - 6.6 mm
Mounting Hole Diameter D Min (Imperial)
0.24
Mounting Hole Diameter D Max (Imperial)
0.26
Mounting Hole Diameter D Max (Metric)
6.6
Material
Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS)
Material Shortcut
PA66HIRHS
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
