Specification Sheet
Part Number:
126-00065
1-Piece Cable Tie/Arrowhead Mount with Seal, 6.5" Long, 50lb Tensile, PA66HS, Natural, 500/bag
Article Number
126-00065
Type
T50SOSSFT6.5E-MS-MD
Color
Natural (NA)
Features & Benefits
•Design helps silence and stabilize the tie in high-vibration applications.
•Arrowhead-style mount provides low insertion and high extraction force. •Anti-
rotational oval fastener forces bundle to travel in intended direction. •Rubber
seal restricts water and debris from passing through mounting hole.
Quantity Per
bag
Product Description
The arrowhead design of these ties offers a positive, low insertion force and a
high extraction force. These ties feature a foam rubber seal which provides
additional protection against moisture, dirt, and other impurities. One-piece
mounting ties offer a complete solution by both bundling cable and at the same
time providing a mounting solution. HellermannTyton’s one-piece mounting ties
offer the ideal combination of high specification materials and superior design
to suit the mounting and bundling needs of complex applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount with Seal, 6.5" Long, 50lb Tensile,
PA66HS, Natural, 500/bag
Global Part Name
T50SOSSFT6.5E-MS-MD-PA66HS-NA
Minimum Tensile Strength (Imperial)
40.0
Minimum Tensile Strength (Metric)
180
Length L (Imperial)
6.5
Length L (Metric)
163.0
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
1.38
Bundle Diameter Max (Metric)
35.0
Thickness T (Imperial)
0.05
Thickness T (Metric)
1.3
Height H (Imperial)
0.63
Panel Thickness Min(Imperial)
0.03
Panel Thickness Max(Imperial)
0.07
Panel Thickness Min (Metric)
0.7
Panel Thickness Max (Metric)
1.6
Mounting Hole Diameter D (Imperial)
0.25 - 0.27
Mounting Hole Diameter D (Metric)
6.1 - 6.6 mm (hexagonal) 6.25 - 6.75 mm
Mounting Hole Diameter D Min (Imperial)
0.25
Mounting Hole Diameter D Max (Imperial)
0.27
Mounting Hole Diameter D Max (Metric)
6.75
Disc Diameter(Metric)
16.0
Disc Diameter (Imperial)
0.63
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
1.51
