HellermannTyton 126-00044 Specification Sheet

Specification Sheet
Part Number:
126-00044
1-Piece Cable Tie/Arrowhead Mount, 6"L, 50lb, 0.04"–0.14" Panel Thickness, PA66, Natural, 1000/pkg
126-00044
Type
T50SSF
Color
Natural (NA)
Features & Benefits
All-in-one bundling and fastening solution reduces costs and assembly time.
The arrowhead design of these ties offers a low insertion force and a high
extraction force. •
High-spec materials and superior design deliver versatility,
performance and value.
Quantity Per
bag
Product Description
One-piece mounting ties offer a complete solution by both bundling cable and
simultaneously providing a mounting solution. The arrowhead design of this
push mount inserts easily and locks securely in place. HellermannTyton’s
one-piece mounting ties combine high-specification materials with superior
design to deliver dependable performance in a range of applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount, 6"L, 50lb, 0.04"–0.14" Panel Thickness,
PA66, Natural, 1000/pkg
Global Part Name
T50SSF-PA66-NA
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
6.25
Length L (Metric)
159.0
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
1.4
Bundle Diameter Max (Metric)
35.0
Height H (Imperial)
.30
Height H (Metric)
7.50
Panel Thickness Min(Imperial)
0.039
Panel Thickness Max(Imperial)
0.14
Panel Thickness Min (Metric)
1.0
Panel Thickness Max (Metric)
3.56
Mounting Hole Diameter D (Imperial)
0.25 " - 0.28
Mounting Hole Diameter D (Metric)
6.4 - 7.1 mm
Mounting Hole Diameter D Min (Imperial)
0.25
Mounting Hole Diameter D Max (Imperial)
0.28
Mounting Hole Diameter D Max (Metric)
7.1
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
ROHS Complaint
Yes
UL Recognized (US)
Yes
UL Recognized (US and Canada)
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
