Specification Sheet
Part Number:
126-00042
1-Piece Cable Tie/Arrowhead Mount with Wings, 4.5"L, 18lb, 0.19 - 0.22" Mtg Hole, PA66HS, Black,
1000/pkg
Article Number
126-00042
Type
T18RWPM
Color
Black (BK)
Features & Benefits
•
Two piece assembly allows the mount to slide along the strap ensuring proper
orientation. •
Arrowhead style mount provides low insertion and high extraction
force. •
Arrowhead disc protects against dirt and other impurities.
Quantity Per
bag
Product Description
Wing design helps stabilize the tie in high vibration applications. One-piece
mounting ties offer a complete solution by both bundling cable and
simultaneously providing a mounting solution. HellermannTyton's one-piece
mounting ties offer the ideal combination of high specification materials and
superior design to suit the mounting and bundling needs of complex
applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount with Wings, 4.5"L, 18lb, 0.19 - 0.22" Mtg
Hole, PA66HS, Black, 1000/pkg
Global Part Name
T18RWPM-PA66HS-BK
Minimum Tensile Strength (Imperial)
18.0
Minimum Tensile Strength (Metric)
80
Length L (Imperial)
4.5
Length L (Metric)
113.0
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.1
Width W (Metric)
2.5
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
0.86
Bundle Diameter Max (Metric)
22.0
Thickness T (Imperial)
0.043
Thickness T (Metric)
1.1
Height H (Imperial)
.23
Height H (Metric)
5.80
Panel Thickness Min(Imperial)
0.06
Panel Thickness Max(Imperial)
0.13
Panel Thickness Min (Metric)
1.52
Panel Thickness Max (Metric)
3.2
Mounting Hole Diameter D (Imperial)
0.19 - 0.22
Mounting Hole Diameter D (Metric)
4.8 - 5.6 mm
Mounting Hole Diameter D Min (Imperial)
0.19
Mounting Hole Diameter D Max (Imperial)
0.22
Mounting Hole Diameter D Max (Metric)
5.6
Disc Diameter(Metric)
13.2
Disc Diameter (Imperial)
0.5
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Certification/Specification WEB
UL
UL Recognized (US)
Yes
UL Recognized (US and Canada)
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
